| Lens Mount |
Canon RF |
| Image Sensor |
Full-Frame CMOS |
| Effective Sensor Resolution |
34.2 Megapixel (7144 x 4790) |
| Image Stabilization |
No (Camera Body); Yes (Lens) |
| ISO/Gain Sensitivity |
Dual Base: 800 / 6400; Native: 100 to 25,600 (100 to 25,600 Extended); Dual Base: 400 / 3200; Native: 800 to 51,200 (800 to 102,400 Extended) |
| Max Recording Modes |
Raw 12-Bit up to 6.9K at 29.97 fps; XF-HEVC S 10-Bit up to 6.9K at 29.97 fps; XF-AVC 10-Bit up to DCI 4K at 59.94 fps |
| Media/Memory Card Slot |
Slot 1: SD/SDHC/SDXC; Slot 2: CFexpress Type B |
| Video I/O |
1x HDMI Output |
| Mobile App Compatible |
Yes: Android & iOS |
| Battery |
Canon LP-E6, Canon LP-E6NH |
| Lens Communication |
Yes: Cooke /i |
| Built-In ND Filter |
No |
| Capture Type |
Stills & Video |
| Shutter Type |
Electronic Rolling Shutter |
| Shutter Speed |
1/16000 to 30 Seconds |
| Shutter Angle |
11.25 to 360° |
| Advertised Dynamic Range |
16 Stops |
| Focus Mode |
Automatic, Continuous-Servo AF, Manual Focus, One-Shot AF |
| Fast-/Slow-Motion Support |
Yes |
| Gamma Curve |
Canon Log 2, Canon Log 3, Hyper Gamma |
| Built-In Microphone |
Stereo |
| Audio Recording |
4-Channel 24-Bit 48 kHz LPCM (Raw, XF-AVC); 2-Channel 16-Bit 48 kHz AAC (XF-HEVC S) |
| IP Streaming |
RTP, RTSP, SRT, UDP up to 1920 x 1080 |
| Audio I/O |
2x XLR 3-Pin Mic/Line Input on Handle; 1x 3.5mm Stereo Mic Input; 1x 3.5mm Stereo Headphone Output |
| Power I/O |
1x USB-C |
| Other I/O |
1x 2.5mm Sub-Mini Remote; 1x USB-C (Ethernet, UVC 1.5); 1x DIN 1.0/2.3 Timecode; 1x Proprietary |
| Wireless |
Wi-Fi / 2.4 GHz Radio/RF / 5.8 GHz Radio/RF |
| Display Type |
Articulating 3" Touchscreen LCD |
| Operating Conditions |
23 to 113°F / -5 to 45°C at 60 to 85% Humidity |
| Shoe Mount |
1x Intelligent Hot Shoe |
| Accessory Mounting Thread |
1x 1/4"-20 |
| Dimensions (W x H x D) |
5.6 x 3.5 x 3.7" / 143 x 88 x 95 mm (Body Only); 8.7 x 9.4 x 7.3" / 222 x 239 x 186 mm (With Handle, Mic Holder) |
| Weight |
23.5 oz / 665 g (Body Only); 2.4 lb / 1110 g (With Battery, Handle, Recording Media) |
| Package Weight |
4.015 lb |
| Box Dimensions (LxWxH) |
11.3 x 8.2 x 6" |
| Focal Length |
24 to 70mm |
| Aperture |
Maximum: f/2.8; Minimum: f/22 |
| Lens Format Coverage |
Full-Frame |
| Angle of View |
84° to 34° |
| Minimum Focus Distance |
8.27" / 21 cm |
| Magnification |
1:3.33 Macro Reproduction Ratio; 0.3x Magnification |
| Optical Design |
21 Elements in 15 Groups |
| Aperture/Iris Blades |
9, Rounded |
| Focus Type |
Autofocus |
| Filter Size |
82 mm (Front) |
| Lens Dimensions |
ø: 3.48 x L: 4.95" / ø: 88.5 x L: 125.7 mm |
| Lens Weight |
1.98 lb / 900 g |
