| Lens Mount |
Canon RF |
| Image Sensor |
Full-Frame BSI Stacked CMOS |
| Effective Sensor Resolution |
19.05 Megapixel (6008 x 3170) |
| Image Stabilization |
Digital, 5-Axis |
| ISO/Gain Sensitivity |
Native: 100 to 102,400 |
| Max Recording Modes |
Cinema RAW Light 12-Bit Up to 6K at 23.98/24.00/25/29.97 fps XF-AVC S Intra 4:2:2 8/10-Bit Up to DCI 4K at 50/59.94/120 fps XF-AVC S Long GOP 4:2:0 8-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Long GOP 4:2:2 10-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Long GOP 4:2:0 10-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Intra 4:2:0 8-Bit Up to DCI 2K at 23.98/24.00/25/29.97/50/59.94 fps XF-HEVC S Long GOP 4:2:0 10-Bit Up to DCI 2K at 23.98/24.00/25/29.97/50/59.94/60.00 fps XF-HEVC S Long GOP 4:2:0 8-Bit 720p at 23.98/24.00/25/50/59.94 fps |
| Max Video Output |
via HDMI / SDI/BNC / USB DCI 4K |
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC |
| Mobile App Compatible |
Yes: iOS Only Functionality: Adjust Settings, Remote Control, View Live Feed |
| Battery |
Canon BP-AN Series |
| Lens Communication |
Yes: Cooke /i |
| Actual Sensor Resolution |
26.67 Megapixel (6202 x 4300) |
| Built-In ND Filter |
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters |
| Internal Filter Holder |
No |
| Capture Type |
Stills & Video |
| Shutter Type |
Electronic Rolling Shutter |
| Shutter Speed |
1/2000 to 1 Second |
| Shutter Angle |
11.25 to 360° |
| Advertised Dynamic Range |
16 Stops |
| White Balance |
Range: 2000 to 15,000K Presets: AWB, Daylight, Set A, Set B, Tungsten |
| Focus Mode |
Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, One-Shot AF |
| Internal Recording |
Cinema RAW Light 12-Bit 6000 x 3164 at 23.98/24.00/25/29.97 fps (553 to 639 Mb/s) 4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps (293 to 678 Mb/s) XF-AVC S Intra 4:2:2 8/10-Bit 4096 x 2160 at 50/59.94/120 fps (150 to 600 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94/120 fps (150 to 500 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/120/180 fps (35 to 300 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/120/180 fps (35 to 300 Mb/s) XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 at 50/59.94/120 fps (150 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (100 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) XF-HEVC S Long GOP 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps (225 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (135 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps (50 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps (50 Mb/s) XF-HEVC S Long GOP 4:2:0 10-Bit 4096 x 2160 at 50/59.94/120 fps (150 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (100 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps (35 Mb/s) XF-HEVC S Intra 4:2:0 8-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps (9 to 16 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps (9 to 16 Mb/s) 1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps (6 Mb/s) *Sensor Crops During Recording XF-HEVC S Long GOP 4:2:0 10-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps (9 to 16 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps (9 to 16 Mb/s) XF-HEVC S Long GOP 4:2:0 8-Bit 1280 x 720 at 23.98/24.00/25/50/59.94 fps (6 Mb/s) |
| Video Output |
via HDMI / SDI/BNC / USB 4096 x 2160 |
| Fast-/Slow-Motion Support |
Yes |
| Gamma Curve |
Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020 |
| Built-In Microphone |
Stereo |
| Audio Recording |
Cinema RAW Light: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC S, XF-HEVC S: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC S, XF-HEVC S: 2-Channel, 16-Bit at 48 kHz via AAC Audio |
| IP Streaming |
H.264, MPEG2, RTP, RTSP, SRT, UDP 1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s) |
| Internal Storage |
No |
| Video I/O |
1x BNC (12G-SDI) Output 1x HDMI Output |
| Audio I/O |
2x Mini XLR Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1x Barrel (23.7 to 25VDC) Input |
| Other I/O |
1x RJ45 (XC) Control 1x USB-C Monitor 1x BNC (Timecode) (Shared with Video Output) 1x 2.5 mm Sub-Mini (LANC) Control |
| Wireless |
Wi-Fi 5 (802.11ac) |
| Global Positioning (GPS, GLONASS, etc.) |
No |
| Display Type |
Primary Monitor: Included External 3.5" Touchscreen LCD |
| Resolution |
Primary Monitor: 1280 x 720 |
| Power Consumption |
≤19.6 W |
| Operating Conditions |
32 to 104°F / 0 to 40°C up to 85% Humidity |
| Storage Conditions |
23 to 113°F / -5 to 45°C up to 60% Humidity |
| Shoe Mount |
1x Intelligent Hot Shoe |
| Tripod Mount |
1x 3/8"-16 Female 2x 1/4"-20 Female |
| Netflix Approved |
Yes |
| Dimensions (W x H x D) |
6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm 10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder) |
| Weight |
2.87 lb / 1.30 kg (Body Only) 3.406 lb / 1.545 kg (With Battery, Handle) |
| Package Weight |
6.385 lb |
| Box Dimensions (LxWxH) |
11 x 8.9 x 7.4" |
